嵌入式LED鍵盤
全面的保護(hù)功能 |
|
| 物料編碼 | (單相AC 200…240V, -10/+10%, 50/60Hz) | 過載((150%, 60s) | 機箱 | 寬
(mm) | 高
(mm) | 深
(mm) |
| R912006807 | VFC3210-0K40-1P2-MNA-7P-NNNNN-NNNN | 0.40 kW, 2.4 A | A | 90 | 135 | 105 |
| R912006808 | VFC3210-0K75-1P2-MNA-7P-NNNNN-NNNN | 0.75 kW, 4.1 A | B | 95 | 145 | 120 |
| R912006809 | VFC3210-1K50-1P2-MNA-7P-NNNNN-NNNN | 1.50 kW, 7.3 A | C | 95 | 185 | 125 |
| R912006810 | VFC3210-2K20-1P2-MNA-7P-NNNNN-NNNN | 2.20 kW, 10.1 A | D | 120 | 210 | 130 |
|
|
|
|
|
|
|
| 物料編碼 | (三相AC 380…480V, -15/+10%, 50/60Hz) | 過載(150%, 60s) | 機箱 | 寬
(mm) | 高
(mm) | 深
(mm) |
| R912006811 | VFC3210-0K40-3P4-MNA-7P-NNNNN-NNNN | 0.40 kW, 1.3 A | B | 95 | 145 | 120 |
| R912006812 | VFC3210-0K75-3P4-MNA-7P-NNNNN-NNNN | 0.75 kW, 2.3 A |
| R912006813 | VFC3210-1K50-3P4-MNA-7P-NNNNN-NNNN | 1.50 kW, 4.0 A | C | 95 | 185 | 125 |
| R912006814 | VFC3210-2K20-3P4-MNA-7P-NNNNN-NNNN | 2.20 kW, 5.6 A | D | 120 | 210 | 130 |
| R912006815 | VFC3210-4K00-3P4-MNA-7P-NNNNN-NNNN | 4.00 kW, 9.7 A |
| 注：以上所有價格均為不含稅價 |
|
|
|
|
|
| VFC 3610 變頻器全新小型機械類應(yīng)用 |
